Technical Specification

• Analysis Ranges : 0.01 ppm to 100 %
• Accuracy : +/- 1% Full Scale Range
• Display : LCD with Backlight
• Dimensions : 1/4 DIN (96 x 96 x 65mm)
• Alarms : 2 Adjustable w/ delay mode
• Power : 14 - 28 VDC or 100 - 240 VAC
• Output (Analog) : 4 - 20mA
• Communication : Bi-Directional MODBUS RS485 ASCII
• Range ID : 1 - 5 VDC (Optional 4 -20mA)
• Response time : T90 in 7 Seconds
• Sensor : Configurable
• Sensor Type : Precision Electrochemical
• Calibration : Periodically
• Temperature Compensation : Integral
• Flow Sensitivity : 0.5 - 5 SCFH (0.236 - 2.36 LPM)
• Pressure : 0.1 - 50 PSIG (0.007 - 3.447 bar)
• Warranty : 12 Months Sensor
