Technical Specification

• Analysis Ranges
  CO : 0-1000ppm, CO₂ : 0-25% (TDLAS)
  SO₂ : 0-1000ppm, NO : 0-1000ppm, NO₂ : 0-1000ppm (DOAS)
• Power : 220 ± 15% VAC, 50Hz, 600W
• Gas source : 0.4MPa-0.8MPa, oil-free, water-free and dust-free
• Response time : T₉₀ ≤ 10s (double modules)
• Analog output : 5 X 4-20mA output (depend on gas combination)
• Switch output : 4 relay output
• Digital output : 1 RS485 output
• Ambient temperature : -20°C - 60°C
• Ambient humidity : ≤90%RH, non condensing
• Dimension : 448mm(L)X420mm(W)X240mm(D)
• Weight : About 45Kg
