Technical Specification

• Primary Power : 120 - 220VAC ± 10%, 50 Hz, 2.5Amps
• Standby Power : 24v D.C (2 Nos of 12v, 12Ah SMF battery)
• Display : 16x2 Dot Matrix LCD
• Programmable Input circuits : 04 nos.
• Maximum Manual Release Switch : 03 nos.
• Initiating Device Circuits : Class B Style B/C operation(Programmable)
• Notification Appliance Circuits : 02 nos., Class B, Style - Y wiring
• Releasing Agent Circuits : 02 nos., Class B, Style - Y wiring
• Audio visual indication : Main, Standby status, Battery Low
• Common Relays : 3 nos. Form C programmable relays for Fire / fault / supervisory / Gas Released
• Modes of operations : Auto / Manual
• Communication : RS 485(Optional)
• Specifications Met : UL-864, NFPA-72
• Mounting Type : Wall Mounting/Self Standing Enclosure
• Material of Construction : MS Powder Coated/Stainless Steel Polished
