Technical Specification

• Enclosure : Industrial grade
• Dimensions : in strict accordance with relevant project documentation
• MOC : MS CRCA, stainless steel
• Panel wire minimum cross-sectional area
  1.5 mm2 : 24 VDC from fused terminals
  0.5 mm2 : Analogue/Digital signals, PLC patch wiring, 3 wire instrumentation
  2.5 mm2 : 24 VDC from circuit breaker, Earth
• Termination : terminated into dedicated disconnect terminals
• PVC ducting : Separate for signal and power wiring with 60 % spare capacity
• Earthing : protective earth bar for power, instrument
