Technical Specification

• Material of Construction : 316 Stainless Steel
• Flange : Class 150, ASME/ANSI B16.5
• NPS : 4 inches, other size on request
• Gasket : Non-metallic Full Face, other Material on request
• Filter element, porosity : stainless steel 3 µm, ceramic 2 µm
• Filter chamber volume : 120 cm³
• Probe length : 1200 mm with Head Assembly
• Working temp : up to 800°C
• Option back-purging unit
  Max. back-purge pressure : 6 bar abs
  Volume buffer vessel : 2 liters
• Option heating type
  Ring Heater : Self-regulating
  Low temperature alarm contact : NC-NO, 230 V, 1.5A AC, 0.5 A DC
• Area classification : Safe area
• Case protection : IP54
• Power supply : 230 V, 50 Hz
• Electrical connection : 3 x 1.5 mm2
