Technical Specification

• Material : MS CRCA, SS304, SS316, SS316L
• Thickness : 14#, 16#
• Door : Corner formed in one piece. Surface mounted with 130° opening. Concealed AISI 304 stainless steel hinges with removable pin.
• Sealing : Extruded one piece polyurethane gasket.
• Lock : Chrome plated 5 mm DIN-lock with 90° movement.
• Mounting plate : Fixed onto 1/4" studs welded to the rear of the enclosure. The mounting plate has a fold to all four sides for extra rigidity.
• Cable/Tube access : Gland plate as per requirement
• Finish : SS polish, Powder Coated (colour as per requirement)
• Viewing Window : Toughened Glass, Acrylic (as per requirement)
• Size & Shape : As per requirement
