Technical Specification

• Number of heat exchangers : Single Channel
• Gas flow rate : Max. 100 LPH
• Cooling Capacity : 30°C ± 3°C from Ambient Temperature
• Display : Digital Temperature Indicator cum Controller
• Gas outlet dew point adjustable : 2°C to 10 °C
• Main connection : 110 ~ 220VAC, 50Hz
• Sample gas connection : 6mm OD Tube
• Condensate connection : Condensate Trap
• Cooling Coil : SS 4/6mm tube
• Cooler Body : Stainless Steel
• APPLICATIONS : Lower the dew point of humid gases to prevent condensation in the analyzer.
